Product Introduction
Maximize Your Efficiency with Our Heavy-Duty Gasoline Forklifts
Our gasoline forklift series is engineered for high-intensity operations where speed and reliability are paramount. Compared to diesel models, our gasoline trucks offer lower noise, reduced vibration, and cleaner emissions, making them the ideal choice for businesses that need internal combustion power without the harsh exhaust of diesel engines.
|
Product Packaging
|
Key Features & Advantages
Equipped with high-performance gasoline engine, providing strong torque and stable power output
Excellent low-speed performance ensures efficient handling of heavy loads
Load capacity ranges from 1.5 ton to 5.5 ton, meeting different working requirements
Stable operation on uneven ground, dusty and outdoor working conditions
Instant start and immediate power output, no warm-up or charging time required
High operating efficiency for multi-shift and heavy-duty working scenarios
No battery degradation or charging waiting time, ensuring continuous operation
Mature and reliable engine structure with simple maintenance procedures
Easy access to maintenance points reduces downtime and labor cost
Long service life and strong durability under frequent use
Compact structure and flexible steering for smooth movement in narrow spaces
Ergonomic design with adjustable seat, comfortable control lever and clear instrument panel
Low vibration and reasonable noise level for improved operator comfort during long working hours
Equipped with reliable braking system and stable mast structure
Operator presence system, anti-slip steps and wide-view mirror for enhanced safety
Safe and stable operation even in long-time continuous working
|
Typical Applications
Warehousing & Logistics centers
Construction sites & building materials handling
Agricultural product transportation
Factories & workshops
Ports, yards & outdoor loading-unloading work
Timber and general material handling
|
Why Choose Our Gasoline Forklift?
Strong power and stable performance for heavy-duty work
Immediate operation, no charging or battery issues
Easy maintenance and low long-term cost
High safety, comfort and durability
Suitable for almost all indoor and outdoor working conditions
General | ||
Manufacturer | SHANGCHA | |
Model | CPC(D)30-LPG | |
Power Type | LPG/Bi-Fuel | |
Rated Load Capacity | kg | 3000 |
Load Centre | mm | 500 |
Characteristic & Dimension | ||
Rated Lift Height | mm | 3000 |
Free Lift Height | mm | 140 |
Mast Tilt Angle (F/R, a°/β°) | ° | 6°/10° |
Travel Speed (Full Load/No Load) | km/h | 18/18.5 |
Lifting Speed (Full Load/No Load) | mm/s | 420/480 |
Max.Gradeability(No Load/Full Load) | % | 20/20 |
Turning Radius | mm | 2480 |
Total weight | kg | 4150 |
Wheelbase | mm | 1760 |
Fork Size (LxWxT) | mm | 1070×125×45 |
Fork Overhang | mm | 475 |
Rear Overhang | mm | 515 |
Length to Face of Fork (Without Fork) | mm | 2750 |
Overall Width | mm | 1220 |
Mast Lowered Height | mm | 2070 |
Overhead Guard Height | mm | 2170 |
Chassis | ||
Tyre (Front x 2) | 28×9-15-14PR | |
Tyre (Rear x 2) | 6.50-10-10PR | |
Power &Transmission | ||
Battery | V/Ah | 12/60 |
Engine Model | GK25 | |
Engine Manufacturer | GCT | |
Rated Output /r.p.m. | kw | 37.4/2500 |
Rated Torque /r.p.m. | N·m | 176.5/1600 |
No.of Cylinder | 4 | |
Bore x Stroke | mm | 92x93 |
Displacement | cc | 2472 |
Fuel Tank Capacity | L | 50 |
Transmission Type | HYDRAULIC | |
Transmission Stage (FWD/RVS) | 1/1 | |
Operating Pressure (For Attachments) | Mpa | 17.5 |
MAST SPECIFICATIONS & RATED CAPACITIES | |||||||||||||||
|
|
|
| Overall Height (mm) | Free Lift (mm) | Tilt Angle (Single) | Tilt Angle(Double) | Total Weight | |||||||
Lowered | Extended | Without Backrest | With Bracket | ||||||||||||
Without Backrest | With Backrest | ||||||||||||||
30 | 30 | 35 | 35 | 3.0t/3.5t | 3.0t/3.5t | 30 | 35 | ||||||||
Wide View Mast | M270 | 2700 | 3000 | 3500 | 1920 | 3295 | 3770 | 145 | 150 | 6-12 | 4436 | 4751 | |||
M300 | 3000 | 3000 | 3500 | 2070 | 3595 | 4070 | 145 | 150 | 6-12 | 4460 | 4775 | ||||
M330 | 3300 | 3000 | 3500 | 2220 | 3895 | 4370 | 145 | 150 | 6-12 | 4485 | 4800 | ||||
M350 | 3500 | 3000 | 3500 | 2320 | 4095 | 4570 | 145 | 150 | 6-12 | 4500 | 4825 | ||||
M370 | 3700 | 3000 | 3400 | 2420 | 4295 | 4770 | 145 | 150 | 6-6 | 4515 | 4840 | ||||
M400 | 4000 | 2950 | 3250 | 2620 | 4595 | 5070 | 145 | 150 | 6-6 | *6-12 | 4540 | 4865 | |||
M430 | 4300 | 2800 | 3100 | 2770 | 4895 | 5370 | 145 | 150 | 6-6 | *6-12 | 4565 | 4890 | |||
M450 | 4500 | 2600 | *2900 | 2900 | *3000 | 2870 | 5095 | 5570 | 145 | 150 | 6-6 | *6-12 | 4580 | 4905 | |
M470 | 4700 | 2500 | 2800 | 2800 | 2900 | 2970 | 5295 | 5770 | 145 | 150 | 6-6 | *6-12 | 4595 | 4920 | |
M500 | 5000 | 2200 | *2550 | 2400 | *2800 | 3170 | 5595 | 6070 | 145 | 150 | 6-6 | *6-6 | 4630 | 4955 | |
M550 | 5500 | 2000 | *2400 | 2200 | *2600 | 3420 | 6095 | 6570 | 145 | 150 | 3-6 | *3-6 | 4680 | 5005 | |
M600 | 6000 | 1500 | *2000 | 1600 | *2400 | 3670 | 6595 | 7070 | 145 | 150 | 3-6 | *3-6 | 4720 | 5045 | |
| FM270 | 2700 | 3000 | 3500 | 1920 | 3240 | 3715 | 1232 | 757 | 6-12 | 4515 | 4840 | |||
FM300 | 3000 | 3000 | 3500 | 2070 | 3590 | 4065 | 1382 | 907 | 6-12 | 4540 | 4865 | ||||
FM330 | 3300 | 3000 | 3500 | 2220 | 3940 | 4415 | 1532 | 1057 | 6-12 | 4565 | 4890 | ||||
FM350 | 3500 | 3000 | 3500 | 2320 | 4090 | 4565 | 1632 | 1157 | 6-12 | 4580 | 4905 | ||||
FM370 | 3700 | 3000 | 3500 | 2420 | 4240 | 4715 | 1732 | 1257 | 6-6 | 4595 | 4920 | ||||
FM400 | 4000 | 3000 | 3250 | *3500 | 2670 | 4590 | 5065 | 1982 | 1507 | 6-6 | *6-12 | 4620 | 4945 | ||
3-Stage Full | TFM400 | 4000 | 3000 | *3000 | 3000 | *3500 | 1960 | 4700 | 5175 | 1272 | 797 | 6-6 | *6-6 | 4670 | 4995 |
TFM430 | 4300 | 2800 | *2900 | 3000 | *3350 | 2060 | 5000 | 5475 | 1372 | 897 | 6-6 | *6-6 | 4700 | 5025 | |
TFM450 | 4500 | 2600 | *2800 | 2800 | *3200 | 2110 | 5200 | 5675 | 1422 | 947 | 6-6 | *6-6 | 4720 | 5045 | |
TFM470 | 4700 | 2400 | *2700 | 2500 | *3000 | 2160 | 5400 | 5875 | 1472 | 997 | 6-6 | *6-6 | 4740 | 5065 | |
TFM500 | 5000 | 2100 | *2400 | 2300 | *2800 | 2260 | 5700 | 6175 | 1572 | 1097 | 6-6 | *6-6 | 4750 | 5075 | |
TFM550 | 5500 | 1650 | *2250 | 1800 | *2550 | 2460 | 6200 | 6675 | 1772 | 1297 | 3-6 | *3-6 | 4800 | 5125 | |
TFM600 | 6000 | 1200 | *2100 | 1300 | *2300 | 2660 | 6700 | 7175 | 1972 | 1497 | 3-6 | *3-6 | 4870 | 5195 | |
TFM650 | 6500 | 950 | *1700 | 1050 | *1800 | 2910 | 7200 | 7675 | 2200 | 1747 | 3-6 | *3-6 | 5020 | 5345 | |
TFM700 | 7000 | 650 | *1400 | 750 | *1500 | 3110 | 7700 | 8175 | 2300 | 1947 | 3-6 | *3-6 | 5070 | 5395 | |
1. With Separated Side shifter , load capacity subtract 200Kg,With Integrated side shifter , load capacity subtract 50Kg. | |||||||||||||||
2. * (Asterisk ) is for double front wheels model. | |||||||||||||||
